INFO

Product group
All terrain cranes
Brand / model
Sany STC 500
Year of Mnftr
2021
Usage hours
3 100 h
Country
China
General grade
1
2
3
4
5
Mascus ID
763A03A3

PRICING

Currency Converter

DETAILS

Internal stock No.
1
Latest inspection/checkup date
2025-09-19
Manufacturing number
1
Amount of previous owners
1
Gross Weight
42 000 kg
Maximum lift capacity
50 000 kg
Registration number
1
Max lifting capacity at end of jib
8 000 kg
Min boom length
300 cm
Emission class
Stage V / Tier V
Boom length
4 550 cm
Min luffing jib
800 cm
Luffing jib
1 150 cm
Jib length of crane
4 550 cm
Maximum lift height
6 200 cm
Crane type
Fixed jib
Original colour
Yellow&Red
Carrier engine
42000
Engine manufacturer
Weicahi
Transport dimensions (LxWxH)
13750 x 2750 x 650 mm
Carrier type
Wheeled
Condition info/guarantee
1 year
Tyre brand
Original
Front tyres / undercarriage remaining
98
Rear tyres remaining
2
Production country
China
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Attachments
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessories
Hook blocks
Other information / specs
Sany Heavy Industry STC500 crane parameter configuration Lifting capacity Maximum rated lifting capacity (t) 50 The maximum rated lifting torque (KN.m) is 1788.5 The maximum rated lifting moment of the full extension arm (KN.m) is 840.8 Minimum working range (m) 3 Maximum lifting height - basic arm (m) 12 Maximum lifting height - full reach arm (m) 42.8 Maximum lifting height - basic arm Jib (m) 58.8 Maximum lifting capacity (tons) 45-90 tons Lifting arm size Lifting boom length - basic arm (m) 11.5 Length of the boom - full extension arm (m) 42.5 Lifting arm length - basic arm Knee arm (m) 58.5 The installation angle of the auxiliary lifting arm (°) is 0, 15, 30 Job speed parameters The maximum lifting speed of the main hoist (m/min) is 130 The maximum lifting speed of the auxiliary winch (m/min) is 130 The total extension time of the lifting arm (s) is 120 Rotation speed (rpm) 2 motor Chassis engine model SC9DK320Q3 Rated power (kw/rpm) 251/2200 Driving parameters Maximum travel speed (km/h) 85 Minimum turning radius (m) 11 Maximum climb (%) 40 Approach/Departure Angle (°) 16/12 Minimum ground clearance (mm) 243 Specifications of the whole machine The total length of the whole machine (mm) is 13750 The overall width of the whole machine (mm) is 2750 The overall height of the whole machine (mm) is 3650 Wheelbase (mm) 1450 Operating weight (t) 55
