Manitou 170AETJL
Price excl. VAT
13
Favorite
Share
Save searchPrint
INFO
Product group
Articulated boom lifts
Brand / model
Manitou 170AETJL
Year of Mnftr
2007
Country
Germany
General grade
Mascus ID
E7717723
PRICING
Currency Converter
DETAILS
Internal stock No.
5840
Working height
16,9 m
Power type
Electric
Max horizontal reach
9,70 m
traction sort
2 WD
Gross Weight
6 950 kg
Maximum lift capacity
200 kg
Max swing of arm in degrees
175
Max swing of platform in degrees
175
Transport dimensions (LxWxH)
523000 x 175000 x 223000 mm
Delivery terms
EXW
Certificates
CE
Other information / specs
Manufacturer: Manitou
Model: 170 AETJL
Year of build: 2007
Condition: Used
Data:
Max. working height: 16,85 m
Platform height: 14,85 m
Max. reach: 9,70 m
Platform lifting capacity: 200 kg
Platform dimensions LxW: 1,18 x 0,92 m
Swivel range: +/- 175°
Gradeability: 22%
Total dimensions LxWxH: 6,85x 1,75 x 1,98 m
Transport position LxH: 5,23 x 2,23 m
Movable up to working height: 16,85 m
Wheel pressure max.: 38kN
Ground clearance: 0,12 m
Drive type: Battery
Empty weight: 6.950 kg
Special features: Rotatable work basket, basket arm rotation angle +/- 70°, white tires
GS Arbeitsbühnen GmbH
Jagenbergstraße 21 41468 Neuss Nordrhein-Westfalen Germany
