Other information / specs
Dimensions approx. (excluding container)
Machine width: approx. 2400 mm
Machine height: up to max. 6900 mm
Machine length: 4600 mm
Roller width: approx. 1800 mm
Roller diameter: approx. 1200 mm
Cabin dimensions (LxWxH): 1250 x 880 x 2100 mm
Additional information
Wheelbase: approx. 2500 mm
External turning radius: approx. 9600 mm
Inside turning radius: approx. 2700 mm
Speed: approx. 6 km/h
Max. gradient: max. 6,5° (corresponds to approx. 11%) – without container
Noise level: 78 dB (A) according to DIN ISO 45635 (per 1 m distance)
Container height: min. 2200 mm / max. 3100 mm
Rolling length: approx. 7000 mm, Adjustable from the cab
Total weight: approx. 7500 kg
Roller speed: 12 o/min
Roller weight: approx. 1800 kg
Fuel consumption: approx. 4-5 L ON/h
Total weight: 4.250 kgShow more
