Horyong BMK-403 ECO

Price excl. VAT

POA

Compnay LOGO
Images6
Horyong BMK-403 ECO Other cranes
Horyong BMK-403 ECO Other cranes
Horyong BMK-403 ECO Other cranes
FavoriteFavorite
shareShare
Save searchSave search
Print

INFO

Product group
Other cranes
Brand / model
Horyong BMK-403 ECO
Year of Mnftr
2018
Usage hours
287 h
machine whereabouts
Duisburg, Nordrhein-Westfalen
Country
Germany
General grade
1
2
3
4
5
Mascus ID
A65059D6

DETAILS

Amount of previous owners
1
Gross Weight
4 019 kg
Maximum lift capacity
4 200 kg
Max lifting capacity at end of jib
3 000 kg
Boom length
680 cm
Luffing jib
220 cm
Jib length of crane
680 cm
Maximum lift height
1 020 cm
Hook height of crane - horizontal jib
840 cm
Hook height of crane - luffed jib
221 cm
Upper engine
see chassis
Upper hours
200 h
Original colour
Silber-Grün
Carrier engine
Electric
Transport dimensions (LxWxH)
435000 x 157000 x 205000 mm
Carrier type
Wheeled
Tyre brand
NM-Bereifung
Front tyres / undercarriage remaining
90
Rear tyres remaining
90
Production country
South Korea
Delivery terms
FCA, CPT, EXW
Certificates
CE, TÜV
Attachments
Hakenflasche 1-rollig
Accessories
Hook blocks
Documents
Traglasttabellen-Horyong-BMK-403-ECO-Hauptausleger-abgestutzt.pdf
Other information / specs
Battery industrial yard crane HORYONG BMK-403 ECO, used unit battery drive, CE 2018, approx. 287 working hours Pick+carry and Carry deck TECHNICAL DETAILS: max. lifting capacity 4,2 t x 0,9 m max. load pick + carry 2,9 t max. load on carry deck 2,5 t max. working range 6,7 m (8,2 m with fly jib) max. hook height: 8,41 m (10,2 m with fly jib) DIMENSIONS & WEIGHT length 4.350 mm width 1.570 mm, height 2.050 mm total weight of crane: 4.019 kg outrigger base: 2.330 mm x 3.330 mm CRANE EQUIPMENT: telescopic main boom 3,07 bis 6,8 m, fully hydraulic, 3 sections fly jib with sheave head 2,2 m, max. lifting capacity 1,2 t, angel 0°, 25°, 50° one winch 360° slewing range unlimited Electronical Safe Load Indicator System Rayco Wylie i4500 working range limiter optical and voice warning system working light, emergency stop, round-about light hook block 1-sheave, max. 4,0 t lifting capacity drive 4 x 2 x 2 Carry-Deck for goods, size 1,55 m², max. load 2,9 t 3 pieces pipe holders / transport holders 4-point hydraulic outriggers, front and rear electric engine with batteries, 2x 10 kW, 72V / 300 Ah, rechargable batteries, integrated battery charger max. speed of crane is 6 km/h 4x non marking tires open crane driver cabin with lattice protection roof, operation panel The electric yard crane crane is in good working condition and can be ideally used inside hall areas where exhausts are vorbidden, The unit is immediately available ex our yard and can also be rented for jobsites in Germany.Show more
