Other information / specs
Description: Machine Highlights Make: Case Model: TR310 OROPS Standard Flow 2 Speed Tipping Load: 6200lbs Operating Weight: 8880lbs Hours: 1336 Serial Number: 435954 Engine Model FPT F5H FL463 A*F001 Emissions Certification Tier 4 Final Type Diesel 4-stroke, Turbo, D.I. Cylinders 4 Bore/Stroke 3.9 x 4.3 in Displacement 3.4 L Fuel injection Direct, high pressure common rail – HPCR Dimensions Height to: Bucket hinge pin 123.0 in Top of ROPS 78.7 in Maximum dump angle 39.6° Track on ground 55.9 in (1.42 m) Ground clearance – bottom of belly pan 8.0 in Angle of departure 32.0° Over the track width 74.3 in Engine speeds RPM High idle – no load 2500 +/- 25 Rated – full load 2500 Low idle 1150 +/- 25 Horsepower ... 2500 RPM – SAE J1349: Gross 74 hp Net 68 hp Peak torque ... 1400 RPM 232 lb·ft OPERATING WEIGHT 8,880 lb Shipping weight 8,580 lb Tipping load* 6,200 lb SERVICE CAPACITIES Fuel Tank 19.5 gal Engine oil w/ filter 8.9 qt Hydraulic system: Reservoir 5.3 gal Total 10 gal CASE TR310 HIGH FLOW CAB SKID STEER TRACK LOADER WITH 2 SPEED & HAS OPERATING WEIGHT OF 8,880LBS. SE HABLA ESPAÑOL! FINANCING AVAILABLE! PLEASE CALL US WITH ANY QUESTIONS! ASK ABOUT OUR REASONABLE!
Airconditioning: 0
Coupler: 1
Enginemodel: FPT F5H FL463 A*F001
Fueltype: Diesel
Heater: 0
Ropstype: Open
Quickattach: 0
Breakoutforce: 8680
Bucket: 1
Shippingweight: 8880
Tipload: 6200
Counterweight: 0
Cruisespeed: 5.1
Turbo: 1Show more
