Latest inspection/checkup date
2022
Engine manufacturer
PERKINS
Emission class
Stage V / Tier V
Feed mechanism make
GEOTEC
Condition info/guarantee
1000 Hours / 1 Year
Transport dimensions (LxWxH)
4000 x 1600 x 2400 mm
Front tyres / undercarriage remaining
100
Other information / specs
EVERY MACHINE LEAVING OUR FACTORY - HAS DIFFERENT EQUIPMENT CONFIGURATIONS!
BELOW YOU WILL FIND AN EXAMPLE OFFER! IF YOU HAVE QUESTION, PLEASE CONTACT US!
WE ALSO HELP IN FINANCING!
Drive:
100 kW (136 HP) 4-cylinder turbo diesel engine with Stage 5 and direct drive hydraulic pumps, pressure filter, oil cooler, bypass filter for the hydraulic circuit and AdBlue.
Hydraulic system:
Dual-circuit, load-independent primary hydraulics (1x load-responsive, 1x permanent), proportional, partially direct or remote controlled
Control Valves: Main Control Valves - Auxiliary control blocks partially controlled manually
Pressure indications: system pressure of the hydraulic circuits, supply from the purge pressure
Drive type:
gear with feed, disc brake
Speed: Normal and rapid feed (2 speeds) (Max. 5 possible)
Drilling pressure: max. 2,500 kg
Lifting: max. 9,000 kg
Stroke: 4,200 mm
Drilling gear:
Vibration-stable drilling gear with proportional hydraulic motor.
Speed range: 0 - 350 min-1
Torque range: 0 - 10,000 Nm
Speeds and torques are set with the potentiometer on the control panel.
Drilling pipes;
GT95 (Customization possible)
Maximum mounting diameter on the head:
178 mm (with more adapter)
Grease lubrication system
drilling gear (active cylinders)
Clamping head
Articulated rollers
Sideshift
Middle Pipe Clamp:
Clamping range: Ø80 mm - Ø324 mm
Swivel angle: 30 °
Breakaway torque: 20 kN
Lifting force: 120 kN
Lifting height: 400 mm
Lubrication: Central lubrication beam
Specifications are subject to change.
Each machine is individually equipped.Show more
