Other information / specs
· LS MT7101 PSC
· 101 HP
· Common FPT 4 cylinder, Turbo Charged Intercooled Engine
· 40x40 Power Shuttle Including Creeper Speeds
· High/Low Shift on the fly
· Declutch Button
· Third Function Ready with optional Rear Remotes on Loader Joystick
Engine
• Type 4 Cylinder, CRDI, water-cooled
• Model: f5G
• Emission: Tier 4 Final
• Engine HP (Gross): 100.6
• PTO HP: 85.5
• Rate Speed (RPM): 2,200
• Displacement (cu. In): 206.7
• Fuel Tank Capacity (gal): 30.4
Drive Train
• Transmission Type (option): Power Shuttle
• No. of Speed: 40 x 40
• Forward Speed (mph) 0.1-22.6
PTO
• Type: Independent/Ground Speed PTO
• Rear, rpm: 540/750/1,000
Hydraulic System
• Type: Independent/Ground Speed PTO
• Rear, rpm: 540/750/1,000
Hydraulic System
• Control System: Position/Draft
• Implement pump (gpm): 15.7
• Steering pump (gpm): 6.5
• Total Flow (gpm) 22.2
Category 3 pt Hitch: CAT II
Hitch Lift Capacity lbs: 5,952
Remote Valves: 3 pairs (front, 2 pairs (Rear)
Dimension
• Overall length: 152.2
• Overall width with tires (inch) 78.7
• Wheelbase (inch): 90
• Height to top (inch): 205.4
Weight
• Total weight without ballast (lbs) 7,714
